Vacuum Motor Ametek 2HP to Suit V2S V150S V350S Valet

BRAND: Ness
SKU: VAC-205
$855.60 List price: $1,140.80
+ −
30 Days Return Electricians Unlock Trade Access
Valet Ametek 2HP vacuum motor to Suit V2S, V150S and V350S units. Ideal for central vacuum power units.

Alternatively Known As: Ametek Lamb 117572 Motor, Ametek 117572-12 Vacuum Motor, Valet VAC-205 Replacement Motor, 7.2-inch Central Vacuum Motor

Technical Specifications
  • Motor Model: Ametek Lamb 117572 / 117572-12
  • Rated Power: 2 HP; approximately 1,600 W
  • Voltage: 240 V AC
  • Frequency: 50/60 Hz
  • Fan Stages: Two-stage
  • Discharge Type: Tangential bypass
  • Motor Speed: Single speed
  • Bearings: Double ball bearings
  • Motor Diameter: 183 mm
  • Maximum Airflow: 113.9 CFM
  • Maximum Vacuum: 123.6 inH₂O
  • Air Watts: 482
  • Shaft Diameter: 10 mm
  • Suitable Air: Clean, dry and filtered air only
  • Dimensions (H x L x W): 195mm x 183mm x 183mm
  • Weight: 4.99 kg
Key Features
  • Direct replacement motor for Valet V2S, V150S and V350S units
  • Two-stage tangential bypass configuration for central vacuum systems
  • 240 V AC operation suitable for Australian installations
  • Double ball bearings for reliable motor operation
  • Single-speed design with no speed-control capability
  • Epoxy-coated fan case and aluminium motor brackets
  • Sealed-bearing construction requiring no routine oiling
  • Replacement gasket or seal may be required during installation
Professional Installation Requirements
  • Installation must be performed by a qualified electrician or suitably licensed service technician. Isolate the power supply before fitting, use the correct gasket or seal where required, and verify wiring and motor compatibility. Incorrect installation may void the warranty.
Applications
  • Replacement motor for Valet V2S central vacuum units
  • Replacement motor for Valet V150S central vacuum units
  • Replacement motor for Valet V350S central vacuum units
  • Domestic ducted vacuum power-unit repairs
  • Central vacuum system motor replacement and refurbishment
Standards & Compliance
  • Completed household central vacuum appliances should be assessed against AS/NZS 60335.2.2:2020, Household and similar electrical appliances – Safety – Particular requirements for vacuum cleaners and water-suction cleaning appliances. Compliance of the replacement motor alone is not stated.
Environmental Benefits
  • Extends the service life of an existing central vacuum power unit, reducing whole-unit replacement waste
  • Aluminium motor brackets and copper electrical components are recyclable through appropriate metal-recycling streams
  • Replacement of the motor can retain the existing vacuum canister, ducting and installation infrastructure
Warranty Information

12-month warranty on Valet and iCentral central vacuum replacement motors, subject to the manufacturer's warranty terms and domestic-use conditions. Incorrect installation, misuse or unauthorised servicing may exclude coverage.

Available Now

Available through Valet, Ness Corporation and authorised Australian central vacuum distributors, subject to current supply.
