Vacuum Motor Ametek 7.2 Inch to Suit V3SC and VAC-130 Valet

BRAND: Ness
SKU: VAC-209
$658.50 List price: $877.90
+ −
30 Days Return Electricians Unlock Trade Access
Valet Ametek 7.2 inch vacuum motor to Suit V3SC and VAC-130. Ideal for central vacuum power units.

Alternatively Known As: Central Vacuum Replacement Motor, Ametek Lamb 119921-12 Motor, Valet VAC-209 Motor

Technical Specifications
  • Manufacturer Motor Reference: Ametek Lamb 119921-12
  • Motor Type: Two-stage tangential bypass vacuum motor
  • Fan Diameter: 7.2 inches (183 mm)
  • Operating Voltage: Approximately 240 V AC
  • Frequency: 50/60 Hz
  • Nominal Power: Approximately 1,800–1,850 W
  • Maximum Current: Approximately 7.9–8.25 A
  • Airflow: Up to approximately 123.7 CFM
  • Sealed Vacuum: Up to approximately 137.7 inches water lift
  • Bearings: Double ball bearings
  • Discharge: Tangential
  • Product Reference: Valet VAC-209
  • Dimensions (H x L x W): 197mm x 183mm x 183mm
  • Weight: 2 kg
Key Features
  • Genuine replacement motor for Valet V3SC and VAC-130 power units
  • Suitable for central ducted vacuum systems
  • Two-stage blower configuration for high vacuum performance
  • Tangential bypass design separates cooling airflow from the vacuumed air path
  • 240 V AC operation suitable for Australian installations
  • Designed for clean, dry and filtered air only
  • Double ball-bearing construction
Professional Installation Requirements
  • Replacement involves mains-voltage electrical connections and should be carried out by a qualified electrical or vacuum-system technician. Isolate power before servicing and verify correct motor mounting, wiring, earthing and airflow arrangements.
Applications
  • Replacement of failed or worn motors in Valet V3SC central vacuum power units
  • Replacement of the motor in Valet VAC-130 systems
  • Central vacuum power-unit repairs in residential properties
  • Central vacuum power-unit repairs in offices and other light commercial environments
Standards & Compliance
  • AS/NZS 60335.2.2 is the relevant appliance safety standard for household vacuum cleaners and is applicable to the complete vacuum appliance rather than necessarily representing a separate certification for this replacement motor.
Environmental Benefits
  • Extends the service life of an existing central vacuum power unit, reducing whole-appliance replacement waste
  • The motor's aluminium and copper components are suitable for recovery through appropriate metal recycling streams
  • Restoring the original vacuum unit can reduce the material and energy demand associated with replacing the complete system
Warranty Information

Valet and iCentral central vacuum replacement motors are covered by a one-year warranty against manufacturing defects, for reasonable domestic use and excluding labour, removal, reinstallation and transport costs. ([valet.com.au](https://valet.com.au/uploads/images/23/Valet_warranty_statement.pdf?utm_source=openai))

Available Now

Available through Valet and authorised Australian central vacuum distributors and service dealers. ([valet.com.au](https://valet.com.au/support?utm_source=openai))
