Vacuum Motor Ametek to Suit V3S and V3SW Valet

BRAND: Ness
SKU: VAC-206
$1,244.40 List price: $1,659.20
+ −
30 Days Return Electricians Unlock Trade Access
Valet Ametek vacuum motor to Suit V3S and V3SW units. Ideal for central vacuum power units.

Alternatively Known As: Ametek Lamb 117502-12 Motor, Central Vacuum Replacement Motor, Valet V3S Motor, Valet V3SW Motor

Technical Specifications
  • Motor Model: Ametek 117502-12
  • Operating Voltage: 240 VAC
  • Frequency: 50/60 Hz
  • Rated Current: Approximately 7.3 A
  • Input Power: Approximately 1,700 W
  • Motor Configuration: Three-stage series universal motor
  • Fan System: Tangential bypass
  • Bearings: Dual ball bearings
  • Maximum Airflow: 103.2 CFM
  • Sealed Vacuum: 145.6 inches water lift
  • Maximum Performance: 521 air watts
  • Electrical Connection: Lead wires
  • Duty Cycle: Intermittent
  • Compatible Units: Valet V3S and V3SW
  • Dimensions (H x L x W): 224mm x 183mm x 183mm
  • Weight: 4.5 kg
Key Features
  • Genuine replacement motor for Valet V3S and V3SW central vacuum units
  • Three-stage Ametek motor for central vacuum power units
  • Tangential bypass design separates working air from motor cooling air
  • Suitable for 220–240 V Australian electrical systems
  • Designed for clean, dry and filtered air
  • Replacement motor warranty of 12 months
Professional Installation Requirements
  • Installation must be performed by a qualified electrician or suitably licensed technician. Correct wiring, motor fitment, mounting and sealing are required; incorrect installation may void the warranty.
Applications
  • Replacement of worn or failed motors in Valet V3S central vacuum units
  • Replacement of worn or failed motors in Valet V3SW central vacuum units
  • Central vacuum power units for domestic cleaning systems
Standards & Compliance
  • AS/NZS 60335.2.2:2020 is the applicable safety standard for complete household and centrally sited vacuum cleaners; compliance of the replacement motor as an individual component is not independently stated.
Environmental Benefits
  • Extends the service life of an existing central vacuum power unit, reducing premature replacement and equipment waste
  • Replacement of the motor can avoid disposal of the complete vacuum power unit
  • Designed for durable intermittent operation with ball bearings
Warranty Information

12-month parts warranty from date of purchase for Valet central vacuum replacement motors, subject to correct installation and domestic use. Additional warranty conditions may apply.

Available Now

Available through Valet and authorised Australian distributors.
