Wiring Module for DILM7-M15 | 690 VAC | 15.5 A Rated Current | Compact Design by Eaton
Wiring module designed for DILM7-M15 contactors, featuring a 690 VAC operational voltage and 15.5 A rated current—ideal for electrical panel wiring in industrial applications. Built for secure connections with screw terminals, ensuring compliance with international standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Product Length/Depth: 40 mm
- Product Height: 60 mm
- Product Width: 45 mm
- Ambient operating temperature range: -25 °C to 55 °C
- Rated operational voltage (Ue) max: 690 VAC
- Rated operational current: 15.5 A
- Connection type: Screw terminals
- Heat dissipation capacity Pdiss: 0 W
- Static heat dissipation, non-current-dependent Pvs: 0 W
- Certifications: UL, CSA, IEC/EN 60947-4-1, CE
- Dimensions (H x L x W): 60mm x 40mm x 45mm
- Weight: 0.1 kg
Key Features
- Designed for use with DILM7-M15 contactors
- Screw terminal connections for secure wiring
- Compact size suitable for panel integration
- Meets multiple international certifications including UL, CSA, IEC/EN 60947-4-1, and CE
- Operates in ambient temperatures from -25 °C to 55 °C
- Rated operational voltage up to 690 VAC
- Rated operational current of 15.5 A
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
- Electrical panel wiring for motor starters
- Industrial control systems requiring wiring modules
- Integration with DILM7-M15 contactors
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Compact design reduces material usage
- Complies with international standards ensuring safe and efficient operation
Warranty Information
Warranty terms are provided by Eaton and typically cover manufacturing defects; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton Moeller PKZM0-XDM15ME Wiring Module is available for immediate purchase, ideal for industrial and commercial electrical panel wiring applications.
