Miniature Circuit Breaker 6kA 2 Pole | 63A C Curve | IP40 Protection by NHP
Miniature circuit breaker with 63A C curve and 6kA breaking capacity—ideal for residential and commercial electrical systems. Built for safety, with IP40 protection and reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Miniature Circuit Breaker 6kA 2Pole 63A C Curve
Brand: NHP
SKU: DTCB6263C
Alternatively Known As: Miniature Circuit Breaker, MCB, 2 Pole Circuit Breaker, 63A Circuit Breaker
Technical Specifications
- Rated Current: 63 A
- Number of Poles: 2
- Trip Curve: C
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 6 kV
- Concurrently Switching Neutral Conductor: Yes
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-70 °C
- Dimensions (H x L x W): 86mm x 76mm x 36mm
- Weight: 0.24 kg
Key Features
- Rated current of 63 A with a C curve trip characteristic.
- 6 kA short circuit breaking capacity.
- IP40 protection degree for reliable performance.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 60898 and AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Designed to enhance electrical safety, reducing the risk of fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker 6kA 2Pole 63A C Curve is available now for immediate purchase. Ideal for residential and commercial electrical systems.
