RCBO 25A 6kA 240V 30mA | 4 Module Width | RCD & MCB Protection | by Clipsal
The RCBO 25A 6kA 240V 30mA is a reliable residual current circuit breaker that combines RCD and MCB functionalities in one unit. With a 4 module width, it's designed for easy installation in standard switchboards, providing essential protection against earth leakage, overload, and short circuit faults. Ideal for both residential and commercial applications, this device ensures safety and compliance with Australian standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 25A 6kA 240V 30mA | 4 Module Width | RCD & MCB Protection | by Clipsal
Brand: Clipsal
SKU: SCHA9D32625
Alternatively Known As: Residual Current Circuit Breaker with Overcurrent, RCBO 25A, Clipsal RCBO, 25A 6kA RCBO, SCHA9D32625
Technical Specifications
- Rated current: 25A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Sensitivity: 30mA
- Number of poles: 1P+N
- Mounting: DIN rail
- Width: 4 modules
- Trip curve: C
- Operating temperature: -5°C to +40°C
- Dimensions (H x L x W): 85mm x 75mm x 72mm
- Weight: 0.25 kg
Key Features
- Combines residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 25A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Sensitivity: 30mA for personal protection against electric shock
- 4 module width for easy installation in standard switchboards
- Provides protection against earth leakage, overload, and short circuit faults
- Complies with Australian safety standards
Professional Installation Requirements
- Must be installed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Residential: Protection of final sub-circuits in homes
- Commercial: Offices, retail, and light industrial electrical distribution boards
- General: Suitable for use in switchboards requiring combined RCD and MCB protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009 – Residual current operated circuit-breakers with integral overcurrent protection
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electric shock
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 25A 6kA 240V 30mA 4M (SCHA9D32625) is available for immediate purchase. Ideal for residential and commercial switchboard protection.
